PRIMO 2 WPNT
RIVAL XPLR AXS 1X13 DISCUS 40|30 10th ANNIVERSARY
$7,643.00 CAD
A special livery to celebrate 10 years of exploro on our gateway to gravel, now with hidden cables with a Full-Mount electronic groupset and 3T carbon wheels.
Made to order in 4-6 weeks
Free shipping on orders over 150$
Specifications are subject to change without notice
Sales Taxes are not included in the listed price
Duties/Customs fees are included in the listed price
Contact us
Find a dealer
Looking for a dealer near you? Click here to search for authorized dealers worldwide and locate the nearest one to your location.
More about: Dealer finder
More about shipping & payments
To assure you the best possible delivery service, 3T operates only with top international couriers. All of our deliveries are managed by the DHL group. Deliveries are around 5 working days from time of shipment, except for the “Custom” category: for these products, considering the unique and handcrafted finishing process, deliveries are around 20 days from receipt of the order.
More about: Shipping and Returns
More about returns and refunds
By browsing and purchasing on our website, you agree to our Terms & Conditions. Please review them for detailed information on your rights, order processing, payments, and returns.
More about: Tearms of service
Translation missing: en.products.product.notify_me
Specs
PRIMO2 WPNT ~ RIVAL XPLR AXS 1X13 DISCUS 40|30
- FRAME
- Primo2 UDH
- FRAME MATERIAL
- Unidirectional pre-preg carbon, High-modulus/high-strength performance blend layup
- FORK
- 3T Fango Primo2
- HEADSET
- Sealed cartridge 52/40 (45deg)
- THRU-AXLE
- 100x12 front - 142x12 rear(specific for 3T UDH dropout)
- HANDLEBAR
- 3T Superghiaia Integrale LTD (S&M: 40cm - L&XL: 42cm)
- BAR TAPE
- 3T Prendo Tough
- STEM
- 3T APTO with semi-integrale spacer kit (S:80mm – M:90mm – L: 100mm – XL:110mm)
- BOTTLE CAGE
- 3T nylon front load water bottle cage
- REAR DERAILLEUR
- Sram Rival XPLR AXS E1 MAX 46T
- SHIFT/BRAKE LEVERS
- Sram Rival AXS E1
- BRAKES
- Sram Rival E1 Hydraulic Disc w/ Sram 160mm rotor
- CRANKSET
- Sram Rival E1 XPLR Wide, 40T (51: 170mm - 54&56: 172,5mm - 58: 175mm)
- CASSETTE
- Sram Rival XG 1351 E1 XPLR 10-46T
- WHEELSET
- 3T Discus 40|30
- TIRES
- Pirelli Cinturato Adventure 700×45 or Vittoria Terreno T30 Sport 700×40
- SEATPOST
- 3T Primo setpost for Ritchey clamp
- SADDLE
- Fizik VENTO ARGO X5 140mm
Geometries
* Rider heights are approximations. For more accuracy, compare stack/reach with your current bike.
** Actual stack height is 15 mm higher due to Apto cable cover.
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height* (cm) | 157-170 | 168-180 | 178-191 | 188-201 |
| Rider Height* (inches) | 5'2"-5'7" | 5'6"-5'11" | 5'10"-6'3" | 6'2"-6'7" |
| 01. Stack** | 517 | 546 | 575 | 604 |
| 02. Reach | 366 | 378 | 390 | 402 |
| 03. Headtube angle | 69.5 | 71.1 | 72.5 | 72.5 |
| 04. Fork axle-crown | 395 | 395 | 395 | 395 |
| 05. Headtube length | 101 | 125 | 150 | 180 |
| 06. BB drop | 70 | 70 | 70 | 70 |
| 07. Seattube angle | 72.5 | 72.5 | 72.5 | 72.5 |
| 08. Seattube length | 463 | 490 | 518 | 54 |
| 09. Toptube length | 529 | 550 | 571 | 592 |
| 10. Front center | 591 | 598 | 606 | 627 |
| 11. Rear center | 415 | 415 | 415 | 415 |
| 12. Wheelbase | 996 | 1003 | 1011 | 1032 |
Revolution. Then evolution.
The real revolution was the Exploro.
From that moment on, we chose a different path: not to reinvent the bicycle over and over again, but to improve it without betraying its identity. Every update was driven by experience in the field and by the pursuit of a bicycle that was ever simpler, more effective and more functional.
To us, every new version was never a new beginning; it was another step forward.
The 2018 model was identified by the letters FM, standing for Flat Mount:
the new brake caliper mounting standard that had by then replaced the previous Post Mount interface. But that was only part of the story. The new Fango fork featured cleaner, more minimal lines than the original Luteus; the seatpost clamp became accessible from above, making adjustments easier; and the thru-axles adopted a slimmer design, anticipating a solution still found on today's Primo² models.
Small changes. One clear direction.
Because a good project is never truly finished.
Primo2 WPNT 10th Anniversary
Every project leaves a trace.
After ten years of continuous evolution, we chose to celebrate Exploro with a bicycle that looks forward rather than back. Instead of looking at the past with
nostalgia, it brings together the very best of Exploro's journey and turns it
into the starting point for what comes next.
The graphic design of the Primo² WPNT 10th Anniversary is built by layering together the visual identities that accompanied Exploro between 2016 and 2026.
Paint schemes, logos and graphic elements overlap like chapters of the same story, capturing ten years of evolution in a single design.
Look closer
Alongside these elements, you'll notice a series of technical annotations: colour names, paint codes and finish specifications taken from the original production artwork. From a distance they appear as subtle graphic details; up close, they reveal the work behind the project itself.
The deliberately imperfect lines recall hand-drawn engineering sketches—the moment when every bicycle still exists only as an idea.
Every anniversary celebrates the past. This one celebrates the future.
Because the Primo² WPNT 10th Anniversary is not the final chapter of a story. It's the opening chapter of the next one.
